Suprema D PT-S

Characteristics

  • IP54 or IP44 protection rating
  • Housing color available: white or black
  • Directional luminaires
  • Supply voltage: 230V AC 50Hz (for MT, AT and CT) or 230V AC 50Hz / 220V DC (for CB)
  • Light source: LED diodes
  • Functions: NM – non-maintained version or M – maintained version
  • LiFePO4 batteries with autonomy times 1h, 2h or 3h *, charging 24h
  • Test options: auto test AT (possibility to manually call the test) or central test CT (WELLS system)
  • Ceiling installation recessed
  • Temperature working range: ta 10°C ÷ 40°C
  • Colour temeprature 5000K
  • CRI index: Ra>=70
  • Minimum LED lifetime: 50 000h
  •

Accessories included

Additional accessories

Files to download

Variants available

Catalogue number Name Application of the luminaires Function Test Autonomy Mounting method IP Emergency luminous flux Mains luminous flux Housing color Total power Accessories
94658 M 3H AT IP54 PT-S Directional luminaires Maintained (SA/M) AT – auto test 3H Recessed (PT) IP54 - - White 6W -
93957 M 3H AT IP54 PT-S [BLK] Directional luminaires Maintained (SA/M) AT – auto test 3H Recessed (PT) IP54 - - Black 6W -
94660 M 3H CT IP54 PT-S Directional luminaires Maintained (SA/M) CT – central test / Wells system 3H Recessed (PT) IP54 - - White 6W -
94684 M 3H CT IP54 PT-S [BLK] Directional luminaires Maintained (SA/M) CT – central test / Wells system 3H Recessed (PT) IP54 - - Black 6W -
94640 CB IP54 PT-S Directional luminaires Maintained (SA/M) CB – central battery - Recessed (PT) IP54 - - White 2,5W -
94630 CB IP54 PT-S [BLK] Directional luminaires Maintained (SA/M) CB – central battery - Recessed (PT) IP54 - - Black 2,5W -
